**NEW** Tuson TPMS HEAVY DUTY TRUCK 6-WHEEL HDT BALL SENSOR KIT (RV TPMS-HDT6W-BALL)

Tuson RV Brakes, LLC

Internal Tuson Heavy Duty Truck Tire Pressure Monitoring System with tire ball sensors (TPMS-HDT6W-BALL)

 6 reviews

Regular price$730.00

TPMS-HDT6W-BALL

Tuson Heavy Duty Truck Tire Pressure Monitoring System

Six (6) Wheels Kit

Introducing the NEW Tuson Heavy Duty Truck TPMS. Our automotive-grade internal sensor design provides the most accurate pressure and temperature readings and last 5-10x longer than external sensors. The Tuson Heavy Duty Truck TPMS System can be configured to monitor from 2 to 22 sensors. Each sensor has a unique ID# to identify the sensor to the receiver.

Box Contents:

- One (1) Receiver / Display

- Six (6) Tire Ball Sensors

- One (1) Receiving Box Extension Antenna

Why do you need a TPMS system for your heavy duty truck? Maintaining properly inflated tires has been proven to:

• Increase Fuel Economy
• Extend Tire Life
• Improves steering, stopping and traction
• Increases Environmental Efficiency

Help prevent tire blow-outs by constantly monitoring tire pressure and temperature wirelessly with Tuson Heavy Duty Truck Tire Pressure Monitoring System.

The Tuson Heavy Duty Truck Tire Pressure Monitoring System (TPMS-HDT6W-BALL) instantly detects tire pressure and temperature and transmits that information to the receiver/monitor in the vehicle cab. The wireless tire pressure and temperature sensors can just be dropped inside your truck/trailer tires. The Heavy Duty Truck TPMS allows drivers to monitor the current status of all their truck and trailer tires, increasing towing safety by allowing the driver to monitor all tires while driving.

Internal Ball Sensor

The Tuson Heavy Duty Truck Ball Sensors are automotive-grade internal sensors designed to monitor tire pressure and temperature consistently and wirelessly transmit data to the receiver. Each sensor has a unique ID# to identify the sensor to the receiver.

These are internal sensors that are freely rotating inside the tire to prevent damage and/or theft. Internal sensors provide more accurate pressure and temperature readings than external sensors.

The sensors are motion-activated and will go into sleep mode when the wheels stop moving to preserve sensor battery life. Sensors may take a few minutes to wake-up. Once the wheel speed is over 12 mph/20 kph, the sensor will wake-up and continue transmitting messages to the receiver every minute while moving.

As a general reference, the sensor battery life is about 5 years when driven 4 hours per day. Sold individually.

Receiving Box - Extension Antenna

The Receiving Box Extension Antenna is mounted on the back of the truck in the middle area of the rear bumper.  The cable is routed from the rear bumper to the Receiver/Monitor where it plugs into the monitors harness.  The extension antenna receives the RF signals from the sensors and passes them to the monitor.  The extension antenna receives its power from the cable connected to the monitor’s harness.

Receiver - Monitor

The receiver (monitor) is a 5-inch TFT/LCD touch screen and allows the driver to monitor all tire pressures and temperatures. The system can be configured to monitor from 2 to 22 tires.  The monitor is powered by the truck and does have an internal rechargeable battery that (when fully charged) allows the monitor to be taken back by the wheels to diagnose and pair the individual sensors.  The monitor is also used to set the truck/trailer configurations and parameter settings for pressure and temperature.

Continuously Monitors Critical Tire Monitoring Parameters

• Tire Pressure
• Tire Temperature
• Sensors' Battery Voltage

Visual and Audible Alarms

When the TPMS sensor detects any abnormalities, the sensor immediately transmits visual and audible alarm warnings to the receiver. Never miss a beep!

Easy Installation & Pairing

Each Tuson Heavy Duty Truck TPMS kit comes with designated wheel orientation marks on the surface of each sensor. When each sensor is installed according to the corresponding wheels, no initial pairing is required. Our design makes installation and pairing easy.

Long-term Cost Savings

Using the Tuson Heavy Duty Truck TPMS not only saves you money through increased fuel economy, extended tire life, but the internal sensor has up to 5x the life expectancy of an external cap sensor. Tuson's internal sensors can last up to 10 years, depending on the frequency of use.

Adjustable & Customizable Settings

Customize your trailer tire monitoring settings just the way you like it right at your fingertips. The Tuson Heavy Duty Truck TPMS receiver allows you to select the pressure (kPa, psi, Bar) and temperature (°C, °F) units and set your desired temperature and pressure value to suit your needs.

Interchangeable Wheel Order

No need to remove the TPMS sensor from each tire during a tire rotation. The TPMS receiver allows you to easily change the locations of the sensors according to the tire rotation arrangement.

• TPMS-HDT6W-BALL User Manual
• Ball Sensor Users Guide
• HD Tire Configuration

Receiver - Monitor Specifications

Receiving Box – Extension Antenna Specifications
